We integrate fast speeds, small size, power savings, and high performance in every module. Our full series of optical modules supports fixed access, wireless access, carrier Ethernet, WDM, and data communication networks.
| Product Specifications | |
|---|---|
| Part Number | LS-BL495501-80C |
| Form Factor | SFP |
| Max Data Rate | 155Mbps |
| Wavelength | 1490nm-TX/1550nm-RX |
| Max Cable Distance | 80km |
| Connector | Simplex LC |
| Media | SMF |
| Transmitter Type | FP |
| Receiver Type | PIN |
| TX Power | -5 ~ 2dBm |
| Receiver Sensitivity | < -32dBm |
| EMC Supported | Yes |
| DDM/DOM | Supported |
| Protocols | SFP MSA and SFF-8472 |
| Temperature Range | 0 to 70°C / -40 to 85°C |
| Warranty | 5 Years |
| Part Number | Data Rate | Wavelength | Distance | DDM |
| LS-BL315501-10C | 155Mbps | 1310nm-TX/1550nm-RX | 10km | Yes |
| LS-BL553101-10C | 155Mbps | 1550nm-TX/1310nm-RX | 10km | Yes |
| LS-BL315501-40C | 155Mbps | 1310nm-TX/1550nm-RX | 40km | Yes |
| LS-BL495501-80C | 155Mbps | 1490nm-TX/1550nm-RX | 80km | Yes |
| LS-BL554901-80C | 155Mbps | 1550nm-TX/1490nm-RX | 80km | Yes |
Optical Transport Networks: End-to-end DWDM devices including active modules, amplifiers (EDFA & RFA), Mux/Demux, and ROADM.
Cloud and Enterprise: High-speed optical interconnection solutions ranging from 10G to 800G for mass data transmission.
Wireless Systems: Mature laser and chip solutions for 4G/5G, including WDM and Radio over Fiber.
FTTx Access: Total optical fiber access solutions for global communication network constructers.
Our company is a specialized manufacturer of magnetic telecom and network components, certified by ISO9001:2000, ROSH, REACH, CE and UL. With advanced manufacturing and testing equipment, we provide a complete series of optical modules for fixed access, wireless access, and cloud computing networks. We design, manufacture, and sell products worldwide using the latest optoelectronic technologies.
