| Item | 2.5G SFP |
| Part Status | Active |
| Form Factor | SFP |
| Max Data Rate | 2.5Gbps |
| Wavelength | 850nm |
| Max Cable Distance | 300m |
| Media | MMF |
| Connector | Duplex LC |
| Optical Component | VCSEL/PIN |
| TX Power | -10~-3dBm |
| Receiver Sensitivity | <-18dBm |
| Receiver Overload | -3dBm |
| Power Consumption | 1W |
| Extinction Ratio | >8.2dB |
| DDM/DOM | Supported |
| Temperature Range | -10 to 70°C (-37 to 158°F) |
| Protocols | SFP MSA(INF-8074i), GR-253-CORE, ITU-T G.957, FC-PI v2.0, SFF-8472 v9.5 |
| Warranty | 5 Years |
| Sample | Available |
We are a specialized manufacturer of magnetic telecom and networking components, certificated by ISO9001:2000, ROSH, REACH, CE and UL. Our facility owns advanced manufacturing and test equipment. Established in 1997, we currently have around 2,000 staff members. With a productive capacity of 3,000K units per month, we ensure delivery within short lead times. We provide professional complete solutions for magnetic components along with strong technical support.
