Product Description

⚙️ Specification
✔
RJ45 Connector with integrated transformer / common mode choke.
✔
Power over Ethernet up to 50 Watt and speeds up to 10 Gbit/s.
✔
Available in SMT, THT and THT with USB.
✔
Compliant with standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and upcoming IEE 802.3bt.
✔
HPLE products: Improved Common Mode Rejection due to additional NiZn cores.
RJ45 Connector Specification
Model NumberLow profile rj45 jack
Part StatusActive
Connector TypeRJ45
Applications-LanEthernet(PoE/Non_PoE)
Speed10/100/1000/2.5G/5G/10G Base-T, AutoMDIX
Mounting TypeThrough Hole
Orientation90° Angle (Right)
TerminationSolder
Contact Finish Thickness6.00µin (0.152µm)
LED ColorYellow/Green, Green/Yellow, Green&Yellow/Green&Yellow
Number of Cores per Jack4/6/8/12
ShieldingShielded, Emi Finger
Number of PortsSingle Port
FeaturesBoard Guide
Tab DirectionDown/Up
Contact FinishGold
Configuration RX/TXT,C
Turns Ratio RX/TX1CT:1CT
Operating Temperature0°C ~ 70°C/-40°C ~ +85°C
📦 Packing & Delivery
•
Package: Tray
•
Carton size: 40*32*33cm
•
G.W./carton: 12.3kg
•
Qty/carton: 1200pcs
•
SPQ: 50pcs | N.W/pcs: 0.01kg
Packaging details
🏢 Production & Facilities
Manufacturing process
❓ Frequently Asked Questions
1. How do you guarantee the quality of your RJ45 connectors?
We maintain strict quality control by always providing a pre-production sample before mass production and conducting a final inspection before every shipment.
2. What types of magnetic components can I purchase?
Our product range includes RJ45 Magnetic connectors, Lan transformers, RJ11 Connectors, standard RJ45 Connectors, and SFP modules.
3. What technical standards do your products comply with?
Our products are compliant with IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, and upcoming IEEE 802.3bt standards, ensuring high performance for PoE and high-speed data.
4. Why should I choose your products over other suppliers?
We are a specialized manufacturer with 19 years of experience in RJ45 connectors and LAN transformers. Our facilities are certified by SGS, ISO9001:2008, UL, REACH, and CE, with a high weekly productive capacity.
5. What delivery terms and payment methods are accepted?
We accept various delivery terms including FOB, CFR, CIF, EXW, DDP, and more. Payments can be made via T/T, L/C, Credit Card, PayPal, and Western Union in multiple major currencies.
6. What transmission speeds do these connectors support?
These connectors support a wide range of speeds including 10/100/1000 Base-T as well as high-speed 2.5G, 5G, and 10G Base-T applications.
